Mechanical installation

Mounting

Mounting the shrink disc with a rotating cover

Lenze ¯ MA 12.0014 ¯ 1.0

Gearbox type/size

min

l max.

g500−B45

100

g500−B110

105

120

g500−B240

127

143

g500−B450

134

150

Tab. 5

Dimensions in mm

4.4.5

Mounting the shrink disc with a rotating cover

(

Stop!

Do not dismantle new shrink disc.
Never tighten clamping screws before the machine shaft is pushed in.
Otherwise the hollow shaft may be deformed plastically. Protect the
shrink disc against contact while in operation by appropriate measures
(e.g. cover).
Degrease hollow shaft bore and machine shaft!
