Mechanical installation
Preparation
General information about the assembly of drive systems
4
EN
13 Lenze ¯ MA 12.0014 ¯ 1.0
4.3 Preparation
)
Note!
Thoroughly remove anticorrosion agents from output shafts and flange
faces.
4.3.1 General information about the assembly of drive systems
(
Stop!
The lubricant fill quantity of the gearboxes is matched to the mounting
position. The mounting position indicated on the nameplate must be
observed to avoid damage to the gearbox.
4.3.2 Gearboxes with breathers
(
Stop!
Do not place gearbox onto breather valve!
No ventilation measures are required for the gearboxes g500−B45 ... g500−B240.
Gearboxes which are delivered with a ventilation unit are equipped with a label on the
gearbox.
Remove the transport locking device on the vent valve before the first commissioning.
GT−GNG−13285760.iso/dms
)
Note!
Loosely enclosed vent valves must be mounted in accordance with the
mounting position, (
¶ 29).
