Maintenance
Maintenance operations
Lubricant quantity
8
l
67 BA 12.0023−EN 7.0
Pre−stage GST LL−3; GKSLL−4; GSSLL−3
Mounting
position A B C D E F
GT−GNG−GST/GFL−010.iso/dms
GST05 0.12
0.15
W w1C
0.3
0.35
W w1C
0.15 0.3
0.35
N w1B
0.4 W w1C
0.2 0.2
GST06 0.15 0.4 0.35 0.3
0.4
W w1C
0.3 0.3
GST07 0.3 0.7 0.5 0.55
0.65
M w90
A w80
N w1D
0.4 0.4
GST09 0.6 1.4 1.1 1.2 0.8 0.8
GST11 1.5
2.0
M w132
A w112
N w1G
W w1G
2.5
2.9
M w132
A w112
N w1G
W w1G
2.1 1.7
2.4
M w132
A w112
N w1G
W w1G
1.7 1.7
GST14 2.7
4.0
M w132
A w112
N w1G
4.6
5.2
M w132
A w112
N w1G
W w1G
4.3 3.2
4.1
M w132
A w112
N w1G
W w1G
3 3
Shaft−mounted helical gearbox GFL pre−stage LL−3L
GFL05 0.2 0.2 0.15 0.3
0.35
N w1B
0.4 W w1C
0.12
0.15
W w1C
0.3
0.35
W w1C
GFL06 0.3 0.3 0.35 0.3
0.4
W w1C
0.15 0.4
GFL07 0.4 0.4 0.5 0.55
0.65
M w90
A w80
N w1D
0.3 0.7
GFL09 0.8 0.8 1.1 1.2 0.6 1.4
GFL11 1.7 1.7 2.1 1.7
2.4
M w132
A w112
N w1G
W w1G
1.5
2.0
M w132
A w112
N w1G
W w1G
2.5
2.9
M w132
A w112
N w1G
W w1G
GFL14 3.0 3.0 4.3 3.2
4.1
M w132
A w112
N w1G
W w1G
2.7
4.0
M w132
A w112
N w1G
W w1G
4.6
5.2
M w132
A w112
N w1G
Tab. 9 Amount of lubricant in litres
W
Drive 90...132 Motor size
A, M, N, W Drive−end version 1A ...2K Drive size
