Product description
Transport weights
3
l
24 BA 12.0023−EN 7.0
3.3 Transport weights
Gearbox size Geared motors
Motor frame sizes
063− LL 071− LL 080− LL 090− LL 100− LL 112− LL
G LL03 < 10 < 10
G LL04 < 30 < 30 < 40 < 50
G LL05 < 50 < 50 < 60 < 60 < 70
G LL06 < 70 < 70 < 80 < 90 < 100 < 125
G LL07 < 125 < 125 < 150 < 150 < 175
G LL09 < 200 < 200 < 225 < 225 < 250
G LL11 < 350 < 375 < 375 < 400
G LL14 < 625 < 650 < 650
Gearbox size Geared motors
Motor frame sizes
Gearboxes
132− LL 160− LL 180− LL 200− LL 225− LL
G LL04 < 30
G LL05 < 50
G LL06 < 150 < 70
G LL07 < 200 < 250 < 150
G LL09 < 275 < 325 < 475 < 550 < 250
G LL11 < 425 < 450 < 600 < 700 < 850 < 400
G LL14 < 700 < 750 < 850 < 950 < 1100 < 625
Tab. 1 Transport weights in [kg]; values may differ from table value
