Data transfer
Data transmission slave 2 (AS-i profile 7.A.E)
36
Lenze · Decentralised frequency inverter 8400 motec (AS-Interface option) · EDS84DMOTASI EN 4.0 - 09/2013
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.6 Data transmission slave 2 (AS-i profile 7.A.E)
Accessing the data bits
Bits Signal / I/O mapping Description / standard connection with ...
Inputs
DI0
LP_Network_Out: MCI_bState_B0 C00621/30: not connected
DI1 LP_Network_Out: MCI_bState_B1 C00621/31: not connected
DI2 Digin_bln1 The function of these inputs cannot be selected in the
»Engineer«.
Can be used to monitor the digital inputs if the Drive Unit is
in the "offline" status.
DI3 Digin_bln3
Outputs
DO0
LP_Network_In: MCI_bCtrl_B0 C00701/1: not connected
DO1 LP_Network_In: MCI_bCtrl_B1 C00701/6: not connected
DO2 LP_Network_In: MCI_bCtrl_B2 C00701/5: not connected
DO3 Reserved Reserved for AS-i A/B addressing
