Technical data
Protocol data
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2 Protocol data
Range Values
AS-i device profiles • Slave 1: 7.A.5 (CTT2)
• Slave 2: 7.A.E
Process image, standard Slave 1:
• DI0 ... 3 = 4 bits
• DO0 ... 3 = 4 bits
Slave 2:
• DI0/1 = 2 bits
• DO3/4 = 2 bits
Total: 6 input bits / 6 output bits
Process image, A/B technique Slave 1:
• DI0 ... 3 = 4 bits
• DO0 ... 2 = 3 bits
Slave 2:
• DI0/1 = 2 bits
• DO3 = 1 bits
Total: 6 input bits / 4 output bits
Cyclic parameter data channel
(AS-i spec. V2.0 and V3.0)
4 words (8 bytes)
Acyclic parameter data channel
(AS-i spec. V3.0)
max. 16 double words (64 bytes)
AS-i user data length max. 64 bytes
