Page 46
Electrical installation
Connection data
l
46
EDK94AZRS6 DE/EN/FR/ES/IT 7.0
6.3
Connection data
Mains
Terminal X301
Labelling
Description
L1
L2
L3
Connection of the mains phases L1, L2, L3
+
Connection for the supply−side PE conductor with ring cable
lug M8
SSP94FF606
Terminal data
Max. conductor cross−section
Tightening torque
!
[mm
2
]
[AWG]
[Nm]
[lb−in]
E94AZxS0544
50
0
10
88.5
Hexagon
socket 5
E94AZxS0954
95
000
14
124.0
PE connection data
Æ
Starting torque
!
[mm]
[Nm]
[lb−in]
E94AZxS0544
M8
12
106
SW 13
E94AZxS0954
Standard device
Cable X302
Labelling
Description
1
2
3
Filter output conductor (lead with wire end ferrules, colour
BK)
PE
Output−side PE conductor (lead with wire end ferrule,
colour GN/YE)
SSP94FF607
6.4
Mounting steps
Proceed as follows to connect the filter:
1. Connect the filter output cable (X302) to terminal X100 of the standard
device.
2. Connect the mains cable to terminal X301.
3. Attach the supply−side PE conductor to the PE conductor screw using a
ring or fork−type cable lug.
–
The PE connection must comply with EN 61800−5−1.
