Technical data
Rated data
4
l
36 EDK94AZRS6 DE/EN/FR/ES/IT 7.0
4.2 Rated data
Mains Voltage Voltage range Frequency range
U Lrated [V] U Lrated [V] f [Hz]
3/PE AC 230 180 − 0 % ... 264 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 400 320 − 0 % ... 440 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 500 400 − 0 % ... 550 + 0 % 45 − 0 % ... 65 + 0 %
Voltage Frequency Rated current [A] Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E94AZRS0544 230/400/500 50/60 54.0/54.0/54.0 40.5/40.5/40.5 3
E94AZRS0954 230/400/500 50/60 95.0/95.0/95.0 71.0/71.0/71.0 3
 Temperature in the control cabinet
Power loss Inductance Voltage drop
P loss [W] L [mH] DU [V]
E94AZRS0544 50 ˘ ˘
E94AZRS0954 70 ˘ ˘
