Mechanical installation
Important notes
5
l
38
EDK94AZRS6 DE/EN/FR/ES/IT 7.0
5
Mechanical installation
5.1
Important notes
ƒ
The mounting location must always comply with the operating conditions
specified in the technical data (
¶ 34). Take additional measures if
necessary.
ƒ
The mounting plate of the control cabinet must have the following
properties:
–
electrically conductive
–
free of lacquer
ƒ
The mechanical connections must always be ensured.
ƒ
A free air circulation must be ensured for dissipating the heat.
)
Note!
The filter can be mounted in two ways. From this result different
mounting dimensions.
ƒ
Standard mounting: The filter is mounted underneath the
standard device.
ƒ
Side−by−side mounting: In case of a low depth of the control
cabinet, the filter is rotated by 90° and mounted to the left side
of the standard device.
