Mechanical installation
Side−by−side mounting − device size I
EDK94AZRS DE/EN/FR/ES/IT 6.0
47
l
H1_MechINS−Fi NbMontage_GG2−3_EN
Side−by−side mounting − device size I
Installation steps
How to proceed for side−by−side mounting:
1. Prepare M5 threaded holes on the mounting plate, for instance according to the
mounting grid.
– Always use all mounting points specified.
2. Mount the filter on the prepared mounting plate to the left of the mounting base.
– Use M5 screw and washer assemblies or M5 hexagon socket screws with washers.
– If further devices are to be mounted directly adjacent on the right−hand side of the
filter, do not tighten the screws fully before all devices are mounted and aligned.
– Tightening torque: 3.4 Nm (30 lb−in).
