2 mounting steps, Mounting steps – Lenze EZS3-xxxA200 Sinusoidal filter 180-480A User Manual
Page 27
Mechanical installation
Mounting steps
l
27
EDKZS3−480A200 DE/EN/FR/ES/IT 1.0
3.2
Mounting steps
How to install the filter:
1. Select a suitable mounting place in the control cabinet.
–
Vertical mounting position with fixing bracket below
–
Free spaces: 100 mm to the side and above.
–
A free air circulation must be ensured for dissipating the heat.
2. Screw down the fixing brackets of the filter at the mounting place.
–
The mounting place and material must ensure a durable mechanical
connection.
