18 EDKZS3−480A200 DE/EN/FR/ES/IT 1.0
Scope of supply
Pos. Description
0 Sinusoidal filter EZS3−xxxA200
Mounting Instructions
Elements on the filter
Pos. Description
1 Nameplate
2 Connection 1U1, 1V1, 1W1 (inputs)
3 Connection 1U2, 1V2, 1W2 (outputs)
4 PE connection
5 Shield connection
6 Fixing bracket
7 Blocking point for lifting system
Validity
These instructions are valid for
ƒ sinusoidal filter EZS3−180A200
ƒ sinusoidal filter EZS3−250A200
ƒ sinusoidal filter EZS3−350A200
ƒ sinusoidal filter EZS3−480A200
Identification
Type:
SINUSFILTER
SINE-FILTER
FILTRE-SINUS

L
SSP94SF002

Type code E Z S 3 − xxxA 200
Product series
Accessories
Sinusoidal filter type
3−phase LC filter
Rated current [A]
Variant
