Lenze EZS3-xxxA200 Sinusoidal filter 180-480A - Manual (Page 24)

Technical data
General data and operating conditions
2
l
24 EDKZS3−480A200 DE/EN/FR/ES/IT 1.0
2 Technical data
2.1 General data and operating conditions
Conformity and approval
Conformity
CE 2006/95/EC Low−Voltage Directive
Protection of persons and equipment
Degree of protection EN 60529 IP00
Earth leakage current EN 61800−5−1 > 3.5 mA Observe regulations and
safety instructions!
Insulation resistance EN 61800−5−1 Site altitude < 2000 m: Overvoltage category III
Site altitude > 2000 m: Overvoltage category II
Environmental conditions
Climate
Storage IEC/EN 60721−3−1 1K3 (−25 ... +60 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 ... +70 °C)
Operation IEC/EN 60721−3−3 3K3 (−10 ... +55 °C)
Current derating at +40 ... +55 °C: 2.5 %/°C
Site altitude 0 ... 4000 m amsl
1000 ... 4000 m amsl: Current derating 5 %/1000 m
Pollution EN 61800−5−1 Degree of pollution 2
Vibration resistance (9.81 m/s 2 = 1 g)
Transport IEC/EN 60721−3−2 2M2
EN 61800−2 2 ... 9 Hz: Amplitude 3.5 mm
10 ... 200 Hz: Acceleration resistant up to 10 m/s 2
200 ... 500 Hz: Acceleration resistant up to 15 m/s 2
Operation Germanischer
Lloyd 5 ... 13.2 Hz: Amplitude ±1 mm
13.2 ... 100 Hz: Acceleration resistant up to 0.7 g
IEC/EN 60068−2−6 10 ... 57 Hz: Amplitude 0.075 mm
57 ... 150 Hz: Acceleration resistant up to 10 m/s 2
Mounting conditions
Mounting place In the control cabinet
Mounting position Vertical, fixing bracket below
Free space 100 mm to the side and above
