Technical data
General data and operating conditions
3
l
45 EDK84DGDVBxxx4 DE/EN/FR/ES/IT 5.3
Mounting conditions
Mounting place
Motor mounting Standard
Wall mounting With optional wall
adapter Ensure convection cooling in
the niches!
Mounting position
Wall mounting
E84DGDVB3714
...
E84DGDVB3024
Vertical, cooling rips at
the top Arrangement of several
devices only to the sides, so
that the convection cooling
remains ensured!
E84DGDVB4024
...
E84DGDVB7524
Optional
Control
Control modes
VFCplus:
l V/f control (linear or square−law)
SLVC:
l Sensorless vector control (speed)
VFCplus eco:
l Energy−efficient V/f control
Switching frequency
4 kHz, 8 kHz, 16 kHz,
