Technical data
General data and operating conditions
3
l
44 EDK84DGDVBxxx4 DE/EN/FR/ES/IT 5.3
Supply conditions
Mains connection
Power system
TT, TN
(with an earthed
neutral)
Operation permitted without restrictions.
IT Implement the measure described for IT systems
(remove IT screw).
The machine/system manufacturer is responsible for
compliance with EMC requirements for noise
emission (EN 61800−3) for the machine/plant!
Operation with an integrated safety system is
not permissible.
Motor connection
Motors EN 60034 Only use motors suitable for inverter operation.
Insulation resistance:
at least û
³1.5 kV, at least du/dt ³5 kV/ms
Length of the motor
cable < 20 m (Lenze system cable, shielded)
Ambient conditions
Climatic
Storage IEC/EN 60721−3−1 1K3 (−30 ... +60 °C)
Transport IEC/EN 60721−3−2 2K3 (−30 ... +75 °C)
Operation IEC/EN 60721−3−3 3K3 (−30 ... +55 °C)
Operation at 4 kHz: > +45 °C: Reduce the rated output
current by 2.5 %/°C.
Operation at 8/16 kHz: > +40 °C: Reduce the rated
output current by 2.5 %/°C.
Site altitude < 4000 m amsl
Above 1000 m amsl reduce the rated output current
by 5 %/ 1000 m.
Pollution IEC/EN 61800−5−1 Degree of pollution 2
Mechanical
Vibration resistance (9.81 m/s 2 = 1 g)
Motor mounting Germanischer
Lloyd General conditions: Acceleration resistant up to 2 g
IEC/EN 60721−3−3 3M6
Wall mounting
with
E84DZMAWE1 Germanischer
Lloyd General conditions: Acceleration resistant up to 2 g
IEC/EN 60721−3−3 3M6
