Leica ICC50 HD camera module (cont.)
Mechanical and optical interfaces
Ϙ
FitsbetweenviewingtubeandstandviastandardLeicaMicrosystems
dovetail
Ϙ Centeroffsetofthetopdovetailtothebottom<0.4mm
Ϙ LightdistributionOptical50%/Camera50%
Ϙ Internalvideomagnification0.5×
Ϙ SensorCenteredtoopticalaxis±0.1mm
Ϙ Hoizontally/Verticallyaligned±1degree
Electronic interfaces
Ϙ
ComputerUSB2.0,mini-USBplug
Ϙ
HighDefinitionconnectorMini-HDMI,HD-ready,andfullHD
Ϙ
LEDwith2colorsReady(green),imagecapture(red)
Ϙ IntegratedslotSD(SecureDigital)card
Ϙ 1-8GB,WIFI,WORMsupported
Ϙ Black buton for changing illumination modes (press 1 second), and
switchingfromHDtoPCmode(pressfor3seconds)
Ϙ RedbuttonforcapturewithSDcard(press1second),camerareset
(press10seconds),setnewwhitebalance(press5seconds)
Other
Ϙ
PowersupplyUSB2.0
Ϙ
Powerrequirement4W
Ϙ
Externalpowersupply
Ϙ
Operatingtemperaturerange+5°Cto50°C
Ϙ Relativehumidity10to90%
Ϙ CEDeclarationofConformityAvailable
Ϙ TestedstandardsEMI/RFI:EN55011-BEN50082-1
Ϙ EMC:61000-3-261000-3-3
