Leica ICC50 HD
Manual
21
InPCmode,thecameraimageisalways
shown in the preview window of Leica
ApplicationSuite.Inaddition,anothercomputer
monitorortelevisioncanbeconnectedviathe
HDMIinterface.
The image resolution on the attached
HDMI or television screen is limited to
theliveimageresolutioninsidetheLASEZsoft-
ware.Duetotechnicallimitationsitisnotpossi-
bletoprovideaHD-readyorFull-HDliveimage
streamtotheattachedscreen.Inordertosee
the higher resolution on the attached screen,
pleaseusethecamerain“HD”mode.
Connecting the HDMI monitor
1. Connect the HDMI cable provided to the
LeicaICC50HD.
2. ConnecttheHDMIcabletotheHDMItele-
visionormonitor.
Using an Additional HDMI Monitor in PC Mode
