Leica ICC50 HD: Overview
1. Black Multipurpose button: Press for
1 second – page through illumination
settings. Press for 5 seconds – change
modebetweenHDmodeandPCMode
2. RedMultipurposebutton(onlyactiveinHD
mode):
Ϙ Pressforonesecondtocaptureimageonto
SDCard.
Ϙ
Press for 5 seconds to set white balance
(waitforbeep).
Ϙ Press for 10 seconds to reset camera to
factorysettings(waitforsecondbeep).
1 3
2
4
3. LEDstatusindicator:
Ϙ Green means power is on and ready for
imagecapture.
Ϙ
Red means power is on but not ready for
imagecapture(ie:noSDcard,SDcardfull,
SoftwarenotlaunchedwheninPCmode)
Ϙ
Yellow means initializing. Orange means
camerafailure(restartorcallforservice).
4. SD card Slot: Accepts SD card for stand-
aloneimagecapture.
