Connecting and Configuring your N1 Vision
se
ct
io
n
1
9
2
3
4
5
6
7
8
10
1. Internet Connection
This icon shows you when the N1 Vision is connected to
the Internet.
OFF No Internet connection has
been detected
Solid White N1 Vision is connected to the Internet
Blinking White Internet connection was detected;
N1 Vision is not currently able to
connect to the Internet
2. Modem Connection
This icon shows you when the N1 Vision is connected to
the modem.
OFF Not connected to a modem
Solid White N1 Vision is connected to modem and
functioning properly
Blinking White Problem with modem (such as boot
failure, etc.)
3. N1 Vision (Router) Wireless State
This icon indicates whether or not wireless is enabled.
N1 Vision showing wireless
connection (with curved-lines
illustration) N1 Vision is ON with wireless
enabled and ready for use with
wireless and wired devices
N1 Vision showing wired
connection (without curved-
lines illustration) N1 Vision is ON with wireless
disabled and ready for use
with only wired devices
4. Wired Computers
This icon indicates if there are any wired connections present.
OFF Wired device not present
Solid White Wired device(s) connected to the
N1 Vision
