22 Instruction manual V 1.4 – 04/2010
5. Operation
5.1 Control panel
Fig.10
away from knife
towards the knife
Fig.11
Motorized coarse feed
The motorized coarse feed moves the speci-
men towards or away from the knife!
The fast specimen movement towards the cut-
ting edge must be observed carefully to pre-
vent the specimen from colliding with the cut-
ting edge as this can cause severe damage to
both the knife and the specimen!
On/Off switch
for cryochamber
illumination Display indicating:
- Set / actual temperature
- Real time
- Defrost time
Motorized coarse feed
Forward/
backward
- slow
Forward / backward
- fast
