35 Leica LP C
5.5 Replacing fuses
Before replacing the secondary fuses, always switch the in-
strument off first and unplug it from the power supply.
Fig. 34
Fig. 35
The fuses are located on the rear of the instrument.
• Using a screwdriver (40), pry out the fuse in-
sert (17) and remove it.
40
17
• Remove the defective fuse from the fuse hold-
er (17) and replace it with a replacement fuse
(17a).
Fuse: F 5AL 250 V
• Replace the fuse insert with the replacement
fuse until it clicks into place audibly.
17
17a
5. Cleaning and Maintenance
