12 Operating Manual V 1.0 – 06/2010
3. Instrument Components and Specifications
3.2 Technical data
General
Approvals: The instrument-specific approval marks are located on the
rear side of the instrument next to the identification label.
Nominal voltage: 100 to 240 V +/- 10%
Nominal frequency: 50/60 Hz, 3 A
Classification: Pollution degree 2
Overvoltage installation category II
Laser classification: Class 1 sealed-tube laser,
5-watt output (see Appendix)
Secondary fuses: 2 x F 5 A L, 250 V
Operating temperature range: 5 °C to 40 °C
Relative humidity: 10 % to 80 %, non-condensing
Barcode compatibility: Code 128, Code 39, DataMatrix, PDF417
Connectivity to computer: USB, Ethernet, Serial
Dimensions and weight
Dimensions of basic instrument
Width x depth x height:
254 mm x 457.2 mm x 355.6 mm
Height (with magazine): 635 mm
Weight
Basic instrument: 19.5 kg
Filter unit approx. 13 kg
