Illustrated parts list, Figure 2-1: general assembly, General assembly – Landoll 4630-36 Folding Seeder Parts Manual v.F-641-0513 05/2013 User Manual
Page 7
2-1
Illustrated Parts List
Figure 2-1: General Assembly
GENERAL ASSEMBLY
ITEM
PAGE NO.
DESCRIPTION
QTY.
1
MAIN HITCH AND 8 BOLT HUB AND SPINDLE ASSEMBLIES
2
WING, 6 BOLT HUB AND SPINDLE, AND REAR TOOL BAR
ASSEMBLIES
3
THREE POINT LIFT ASSEMBLY
4
HARROW ASSEMBLIES
5
MARKER ASSEMBLIES
6
SEEDER ASSEMBLY OPTIONS
7
LIGHTING AND ELECTRIC CLUTCH ASSEMBLY
8
HYDRAULIC ASSEMBLIES
9
DECAL INSTALLATION
36’ Seeder Hitch gen assy
5
2
1
7
3
6
8
4
