15 User Manual
Finally, connect the 3-pin Radiator fan
plug to either connection labeled “Fan”
on the Reservoir/Pump unit and replace
the screws on the top fan unit.
Connect a segment of tubing to
each of the remaining nozzles
on the Radiator and Reservoir/
Pump.
This is the loop that will
eventually be connected to
your water blocks.
Water Blocks
Firmly screw tighten the desired
nozzles to the Radiator and
Reservoir. (See “Connecting Hoses”
for further details.)
Next, connect tubing from either
nozzle of the Radiator to the “Outlet”
of the Reservoir/Pump. (The
Radiator does not have a coolant
fl ow orientation.)
NOTE: Make sure to leave enough tubing between the Radiator and Reservoir/Pump
Unit so it can be pulled out a little for fi lling. (Please see “Filling and Maintenance”
for further details.)
