5 User Manual
LED Display Panel
Modes
The PC4/RP-1000 offers seven display options. All are reached by continually
pressing the SET button:
1. Temperature sensor #1 is displayed
2. Temperature sensor #2 is displayed
3. Temperature sensor #3 is displayed
4. All temperature sensors are cycled automatically
5. Fan setting is displayed (“F” is shown as the mode)
6. Pump setting is displayed (“P” is shown as the mode)
7. All temperatures, fan, and pump settings are cycled automatically
Temperature Sensors
PC4/RP-1000 systems can monitor up to 3 temperature sensors (included).
The fi rst LED digit indicates which sensor channel is currently displayed in the
temperature reading. To cycle through sensors, press SET.
Fan Speed
This option adjusts the radiator fan speed. Higher speeds can improve performance,
but will produce more noise. There is 1 automatic and 10 manual fan settings (1-
10). From the fan (“F”) or any cycle mode, press the
▼ or ▲ buttons to adjust fan
settings, or hold down an arrow to skip to the lowest or highest mode directly.
Automatic mode will adjust the fans for you based on temperature values from
sensor #1. This mode is reached by lowering the fan setting to “0” (Aut / A will
be displayed).
Pump Speed
There are 10 manual pump settings (1-10). From the pump (“P”) mode, press
CAUTION: PC4/RP-1000 systems allow full user control of hardware
safety settings, such as audio alarm, shutdown, and pump speed.
Please be sure to confi gure your LED Display Panel properly, or dam-
age to your computer, data, and/or equipment could result. !
Current Mode
Value
Mode Select
Display in ºC or ºF
Decrease Setting
Increase Setting
