AC / DC Voltage: < 1000V, (LOW Z): < 600V
Features:
REL
HOLD
MAX/MIN
RANGE
•
DO NOT use (LOW Z) mode at voltages greater than 600V.
• Use Low impedance (LOW Z) mode to reduce ghost voltages.
• Start with this setting if current level is unknown.
• Attach red lead to “
A
” input.
• Select AC or DC current source.
2.
AC / DC Current (large): < 10A
Features:
REL
HOLD
MAX/MIN
RANGE
3.
AC / DC Current (small): < 400mA
Features:
REL
HOLD
MAX/MIN
RANGE
• Attach red lead to “
mAµA
” input.
• Select µA or mA, and AC or DC current source.
4.
Resistance / Capacitance / Diode / Continuity
•
F
< 4000µF
•
Safely discharge capacitor before measurement.
• Reading may take up to 60 seconds
for large capacitors.
Capacitance Features:
HOLD
•
Do not measure resistance
on a live circuit.
•
Ω
< 40M
Ω
Resistance Features:
HOLD
MAX/MIN
RANGE
PRESS
º
F
º
C
m
Low Z
Duty
Low Z
DTEK
º
F
º
C
m
Low Z
DTEK
º
F
º
C
Low Z
SELECT
Duty
º
Duty
º
F
º
C
m
COM
m
Low Z
DTEK
Duty
º
F
º
C
m
COM
m
Low Z
DTEK
PRESS
TO SELECT
Diode
Resistance
Continuity
Capacitance
º
F
º
C
m
COM
Low Z
Display shows:
• Forward voltage drop if forward biased.
• “O.L.” if reverse biased.
Diode Features:
HOLD MIN/MAX
PRESS
PRESS
REL
