Planting Setup
3. Next, select each box and indicate what you want to see in each location. This allows you to arrange data bars
in order best suited to your needs.
high Row displays a large readout of seed population for the row that is planting at the highest rate as well as singulation
accuracy, skips, and doubles.
Low Row displays a large readout of seed population for the row that is planting at the lowest rate as well as singulation
accuracy, skips, and doubles.
Seed Tanks displays the weight of each bulk fill tank.
Acres to Empty displays how many acres can be planted with the seed remaining in the tank.
Down Force displays the amount of down force being placed on the row unit by the air bags.
Marker Control is used to control the markers. Either the right or left marker can be selected to be deployed. There is also an
auto function that automatically switches the marker whenever the planter is lifted. The OFF button turns both markers off.
NOTE: The electronics do not control the lift of the markers. They only control the deployment. Both markers
can be lifted by using the hydraulics.
