3

KDS Model 200 Series

General Description

This manual applies to the KDS200 series pumps; infusion pumps, models 200, 220, 250;

infusion/withdrawal pumps, models 210, 230; and push/pull pump models 260 and 270.

Most features are common to all pumps. However, the infusion/withdrawal models, 210 and 230

have additional modes and related RS232 commands, not available in infusion only models.

Operation of the pumps is simplified by using a keypad to select features from a menu on

the alphanumeric display.

All control functions are performed automatically by the pump microcontroller and are based

on the syringe diameter and linear motion of the pusher block to deliver a known volume.

After entering the syringe diameter, either directly or from a table in memory, a dispense

volume and flow rate can be entered, and then all calibration and control functions are

performed by the pump automatically.

model

number syringes

infusion

withdrawal

push/pull

200

2

x

210

2

x

x

220

10

x

230

10

x

x

250

4

x

260

4

x

270

4

x

Features

1) Syringe identification

Look up Table

The pump contains a table of standard syringes arranged by manufacturer, material

and size. Once the syringe is identified in the table the pump automatically enters the

appropriate diameter.

Direct Entry

If the syringe used is not included in the table, the internal diameter of the syringe

barrel can be measured in millimeters and entered directly from the keypad.

2)

INFUSION AND REFILL RATES

The infusion rate and, where applicable, the withdrawal rate can be set independently

and can be changed while the pump is running. After the operating mode selection is

made the program will prompt only for the relevant rates associated with that mode.

3)

VOLUME

A target volume can be entered for infusion and refill independently, and the pump

automatically stops when this volume is reached. The pump displays an initial volume of

zero and increases as the dispense proceeds to the target volume. The target volume

can be reviewed or changed as the pump continues to operate.
