7
KDS Model 200 Series
Operating Instructions
(Continued)
KDS260 PUSH-PULL SYRINGE PUMP
Travel direction
Pusher block Syringe clamp
Syringe rest
Anti-syphon clamp
Withdraw bracket
Push-Pull operation: Operate in Withdraw Mode.
Large volume dispenses using large syringes may not require the use of the syringe rest.
Increase travel is possible if the infusion syringe is retained in the left syringe holder without
use of the syringe rest.
KDS260 has all the features of a model KDS210 and, for the push-pull operation the
Withdrawal Mode should be selected from the menu. In this mode the pusher block
will travel from right to left, as shown above.
