KDS Model 200 Series

Operating Instructions

(Continued)

MENU FEATURES

When the pump is first turned on the LCD will display the last Rate or Volume setting. Pressing

Select repeatedly will always return the display to the main menu.

The main menu consists of seven variables, three of which are displayed at all times. The

center variable pulses to indicate that this option can be reviewed or changed.

The menu acts as a continuous loop and the arrow keys,

are used to move

around the loop. Press the Select key to select the variable to be changed.

DIA

TABLE

RATE

VOL

MODE

RS232C

PWR UP

KEYPAD FUNCTIONS

A keypad is used for selection of features from the displayed menu and numerical entries.

KEYPAD

These keys move the displayed menu left and right respectively.

select

Used to select the highlighted menu feature (flashing).

enter

The numerical parameters of the feature selected are set, then enter

places all the settings in memory ready for operation. All settings are

stored in non-volatile memory and will be used next time the pump

is operated.

0 - 9, .

Numerical and decimal entry keys.

run/stop

Starts and stops the motor. Acts as a pause during a dispense.

FAST FORWARD, FAST REVERSE

Keys run and

or

pressed simultaneously causes the pump to run at maximum speed.

This feature can be used for loading, purging and reversing out of a stall condition.
