Data Sheet 902940 Page 2/17
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone: +49 661 6003-0
Fax: +49 661 6003-607
E-mail: [email protected]
Internet: www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
E-mail: [email protected]
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
8 Technology Boulevard
Canastota, NY 13032, USA
Phone: 315-697-5866
1-800-554-JUMO
Fax: 315-697-5867
E-mail: [email protected]
Internet: www.jumousa.com
Technical data
General
Input
Measuring circuit monitoring
Outputs
Reference conditions DIN 16086 and DIN EN 60770
Display Positively lit LCD display
Alignment The display can be mirror-imaged by 180° using the setup program
After installation, the display case can be swiveled to the left or right by ±160°
(use the combination tool)
Size Display 16 × 26 mm / font size 7 mm / 2× 4-digit
Color Standard operation: amber
Error: red (text "Err", error code 1 to 9 flashes)
Setup interface occupied: red
Switching status display K1, K2
Temperature unit °C or °F
Operation
On the device
With the rotary encoder beneath the sealing screw with combination tool or screwdriver
0.5 × 3 mm or Allen key with width across flats SW 2
With PC Via the setup program with PC interface
Measuring input (sensor) 1× Pt1000 temperature sensor, 4-wire circuit
Measuring range Basic type 902940/10: -50 to +150 °C
Basic type 902940/30: -50 to +260 °C
Basic type 902940/50: -50 to +500 °C
Limit deviations 0.15 + 0.002 × |t| a , class A (standard)
0.10 + 0.0017 × |t| a , class AA (1/3 DIN B)
a |t| is the numerical value of the temperature in °C without consideration of the prefix.
Probe short-circuit
Probe and cable break
Measuring range gone below
Measuring range exceeded Analog output 0 to 20 mA, 0 mA or 22 mA configurable
Analog output 4 to 20 mA, 3.4 mA or 22 mA configurable
Analog output 0 to 10 V, 0 V or 10.7 V configurable
Switching outputs, low
Additional error message on the LCD display
All analog outputs in 3-wire circuit/open collector, PNP switching output
Analog output
Can be freely configured
4 to 20 mA and 1× PNP switching output
0 to 20 mA and 1× PNP switching output
0 to 10 V and 1× PNP switching output
Switching output
Quantity
1× PNP switching output
2× PNP switching output
Switching type N/C / N/O
Switching function Window / hysteresis
Contact rating
• Voltage drop from U
B
PNP ≤ 2 V
• Switching capacity ON ≤ 250 mA/OFF ≤ 1 mA
• Switching cycles > 10 million
Reaction time At 50 Hz: ≤ 200 ms
At 60 Hz: ≤ 320 ms
Short-circuit proof Yes
