Order details
(1)
Basic type
a
902940/30
DELOS T
Electronic temperature switch
with display and analog output
with extension tube for higher medium temperatures
Ambient temperature at the display case: -20 to +75 °C
Parts coming into contact with the medium are electropolished,
roughness depth Ra
≤
0.8
μ
m
(2)
Version
x
8
Standard with factory settings
x
9
Customer-specific configuration (specifications in plain text)
(3)
Operating temperature in °C
x
386
-50 to +260 °C
(4)
Measuring insert
x
1013
1× Pt1000 in 4-wire circuit
(5)
Tolerance class according to DIN EN 60751
x
2
Class A (standard)
x
3
Class AA (1/3 DIN B)
(6)
Output
x
470
1× PNP switching output
x
471
2× PNP switching output
x
475
1× PNP switching output and 1× analog output 4 to 20 mA, configurable
x
476
1× PNP switching output and 1× analog output 0 to 20 mA, configurable
x
477
1× PNP switching output and 1× analog output 0 to 10 V, configurable
(7)
Protection tube diameter D in mm
x
6
∅
6 mm
(8)
Insertion length EL in mm (50 to 1000 mm)
x
50
50 mm
x
100
100 mm
x
. . .
Please specify in plain text (50 mm steps)
(9)
Process connection PA
x
000
None (smooth protection tube made out of stainless steel 316L)
x
102
Screw connection G 1/4 (stainless steel 316Ti)
x
103
Screw connection G 3/8 (stainless steel 316Ti)
x
104
Screw connection G 1/2 (stainless steel 316Ti)
x
118
Screw connection M12 × 1.5 (stainless steel 316Ti)
x
126
Screw connection M18 × 1.5 (stainless steel 316Ti)
x
128
Screw connection M20 × 1.5 (stainless steel 316Ti)
x
144
Screw connection 1/2-14NPT (stainless steel 316Ti)
x
163
Union nut G 3/8 (stainless steel 316Ti)
x
380
Screw connection G 1/2 with CIP-compliant conical seal and EHEDG certificate (stainless steel 316L)
x
601
Taper socket with union nut DN 10 DIN 11851 (milk pipe screw connection) (stainless steel 316L)
x
604
Taper socket with union nut DN 25 DIN 11851 (milk pipe screw connection) (stainless steel 316L)
