2009-03-06/00443951
Data Sheet 70.7040 JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 7/8
Connection diagram
Dimensions
Voltage output 0 10 V
Current output 0(4) 20 mA
4 (+)
5 (-)
6 (+)
7 (-)
Potentiometer
3-wire 2-wire
circuit circuit
Resistance thermometer
3-wire 2-wire
circuit circuit
Setup interface
N (L-)
L1 (L+)
1
2
3
1
2
3
1
2
3
␽
3
1
2
␽
