Data Sheet 70.7040
JUMO GmbH & Co. KG • 36035 Fulda, Germany
Page 3/8
Electrical data
Environmental influences
Housing
Probe and lead break:
- current output 4 — 20mA
- current output 0 — 20mA
- voltage output 0 — 10V
Signal is configurable.
positive signal:
> 21.6mA — < 28mA (24mA typical)
negative signal:
≥ 1.5mA — ≤ 3.6mA (2mA typical)
positive signal:
> 21.6mA — < 28mA (24mA typical)
negative signal: < 0mA (-0.05mA typical)
positive signal:
> 11V — < 14V (12V typical)
negative signal:
< 0V (-0.6V typical)
Supply voltage
110 — 240V AC +10/-15%, 48 — 63Hz
20 — 53V AC/DC, 48 — 63Hz
Power consumption
4VA
3VA
Electrical safety
to EN 61010, Part 1
overvoltage category III,
pollution degree 2,
for switching cabinet mounting to EN 50178
to EN 61010, Part 1
protection class III,
for operation with SELV/PELV circuits
Test voltage
3700V
500V
Electrical isolation
The supply is electrically isolated from the
input and the output. There is no electrical
isolation between input, output
and setup connector.
The supply is electrically isolated from the
input and the output. There is no electrical
isolation between input, output
and setup connector.
Operating temperature range
-25 to +55°C
Storage temperature range
-40 to +90°C
Storage temperature humidity
rel. humidity
≤ 85%, no condensation
Temperature error
≤ ± 0.01% / °C
1
Climatic conditions
EN 60721-3-3 3K3
rel. humidity
≤
85% annual average, no condensation
Vibration strength
according to GL Characteristic 2
EMC
- interference emission
- immunity to interference
EN 61326
Class B
to industrial requirements
IP enclosure protection
IP20 to EN 60529
1
All data refer to the range end value 10V or 20mA
Material
polycarbonate
Flammability class
UL 94 V0
Dimensions (W x H x D)
22.5 x 93.5 x 60mm
Screw terminal
2,5mm² wire cross-section / 2.5mm wire dia.
Mounting
on 35mm x 7.5mm DIN rail to EN 60715 A.1,
for installation in control cabinets
Operating position
unrestricted
Weight
approx. 100g
