Order details
Surface-mounting thermostats, type series ATH.-SW
Order
code (1) Basic type
603035 Surface-mounting thermostat, type series ATH.-SW
(2) Basic type extension
0002 ATH.-SW-2 Temperature monitor TW
Single thermostats 0020 ATH.-SW-20 Safety temperature monitor STW (STB)
0070 ATH.-SW-70 Safety temperature limiter STB
0202 ATH.-SW-22 TW / TW
Double thermostats
0220 ATH.-SW-220 TW / STW (STB)
0270 ATH.-SW-270 TW / STB
2020 ATH.-SW-2020 STW (STB) / STW (STB)
2070 ATH.-SW-2070 STW (STB) / STB
7070 ATH.-SW-7070 STB / STB
(3) Design
1 ATHs-SW-.... with rigid shaft
2 ATHf-SW-.... with capillary
(4) Control / limit value ranges °C
014 -20...+50*
*only for TW
016 -10...+40*
021 0...+50
022 0...+70
025 0...+100
041 +20...+90
052 +30...+110
042 +20...+120
066 +60...+130
043 +20...+150
062 +50...+200
063 +50...+250
064 +50...+300
045 +20...+400
046 +20...+500
(5) Hysteresis
00 without hysteresis (-70 STB)
15 1.5 % of the scale range (only for TW)
20 2 % of the scale range (only for STW (STB))
30 3 % of the scale range (only for TW)
50 5 % of the scale range (only for TW + STW (STB))
60 6 % of the scale range (only for TW)
70 7 % of the scale range (only for STW (STB))
90 9 % of the scale range (only for STW (STB))
