3 Mounting
14
3.5.2 Probe mountings 10, 15, 21, 60, 65
Materials Choice of steel, stainless steel or brass
Loading Only for use in unpressurized media.
*depending on the control range
3.6 Mounting the probe
Probe mounting 15 60, 65 10, 21
Maximum temperature +55°C +200°C* +500°C*
The temperature probe (2) must be immersed in the medium for its entire
length, otherwise there will be appreciable deviations from the switching point.
In the case of probe mountings 20, 21 and 23, the temperature probe is
secured in the pocket by a clamping clip (1).
( 1 )
( 2 )
