6 Technical data (extract from data sheet)
36
6.7 Environmental influences
6.8 Housing
6.9 Approvals/marks of conformity
Ambient temperature range 0 to +50 °C
Ambient temperature effect 0.03 %/°C
Storage temperature range -20 to +60 °C
Climatic conditions
 75 % relative humidity, no condensation
EMC EN 61326-1
• interference emission Class A - only for industrial use -
• immunity to interference to industrial requirements
Housing front zinc die-casting, optionally in stainless steel (extra code)
Housing type housing for flush-panel mounting to IEC 61554, in stainless steel
Bezel size 144 mm × 144 mm to IEC 61554
Depth behind panel 193 mm (incl. terminals)
Panel cut-out 138
+1.0
mm × 138
+1.0
mm to IEC 61554
Panel thickness 2 to 40 mm
Housing mounting in panel to DIN 43834
Operating position unrestricted, but taking into account the viewing angle of the screen,
horizontally ±65°, vertically +40° to -65°
Enclosure protection to EN 60529 Category 2, front IP65, rear IP20
Weight approx. 3.5 kg
Mark of conformity Testing
laboratory
Certificates/
certification
numbers Test basis valid for
c UL us Underwriters
Laboratories E 201387 UL 61010-1
CAN/CSA-
C22.2 No. 61010-1 the flush-mounted
instrument; not in
conjunction with extra
code 350
II 2G Ex px IIC
II 2D Ex px IIIC IP65 electrosuisse SEV 08 ATEX 0155 U EN 60079-0:2009
EN 60079-2:2007
EN 61241-4:2006 the flush-mounted
instrument; only in
conjunction with
extra code 444 and
without extra code
350
