2 Identifying the instrument version
12
2.2 Order details
List extra codes in sequence, separated by commas.
(1)
Basic type
706585
LOGOSCREEN fd
(2)
Basic type extension
0
No software package
1
With software package (setup program, PCA3000, PCC, PCS, PCAT, USB cable)
(3)
Language / Setup
8
Factory setting (German/English)
9
Set to customer specification
(4)
Module slot 1
0
Not used
2
3 analog inputs and 8 binary inputs/outputs
3
6 analog inputs
(5)
Module slot 2
0
Not used
2
3 analog inputs and 8 binary inputs/outputs
3
6 analog inputs
(6)
Module slot 3
0
Not used
1
6 relay outputs
2
3 analog inputs and 8 binary inputs/outputs
3
6 analog inputs
(7)
Voltage supply
25
AC/DC 20 to 30 V, 48 to 63 Hz
33
AC 100 to 240 V +10/-15 %, 48 to 63 Hz
(8)
Extra codes memory
020
Lithium battery for memory buffering (ex-factory)
021
Storage capacitor
(9)
Extra codes
.
Not used
260
Math and logic module
(10)
Extra codes housing
.
Not used
350
Universal carrying case TG-35
a
444
Stainless steel front with touchpad
(11)
Extra codes
.
Without extra codes
267
PROFIBUS-DP interface
a
This extra code is available in combination with voltage supply AC 100 to 240 V, not with low supply voltage.
UL and ATEX approvals not applicable. The protection type in the carrying case corresponds to IP20, out-
side IP20D.
Order code
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
Order example
706585
/
-
-
/
,
,
,
