15
3 Installation
3.1 Installation site and climatic conditions
The installation site should be as free as possible from vibration.
Electromagnetic fields, such as those caused by motors, transformers,
frequency converter etc. should be avoided as far as possible.
The ambient temperature at the site can be 0 to 50 °C, at a relative humidity of
 75 %, no condensation.
v Chapter 4.1 “Installation notes”
3.2 Dimensions
Recorder with
zinc diecast
front
Panel cut-out
193
10
21
144
144
