6 Technical data (extract from data sheet)
6.1 Analog inputs
Thermocouple
RTD temperature probe
Designation Measuring range Accuracy
a
a
The linearization accuracy refers to the maximum measuring range. The linearization accuracy is reduced
with short spans.
Fe-CuNi L DIN 43710
Fe-CuNi J EN 60584
Cu-CuNi U DIN 43710
Cu-CuNi T EN 60584
NiCr-Ni K EN 60584
NiCr-CuNi E EN 60584
NiCrSi-NiSi N EN 60584
Pt10Rh-Pt S EN 60584
Pt13Rh-Pt R EN 60584
Pt30Rh-Pt6Rh B EN 60584
W3Re/W25Re D
W5Re/W26Re C
W3Re/W26Re
Chromel-copel GOST R 8.585-2001
Chromel-alumel GOST R 8.585-2001
PLII (Platinel II) -200 to +900 °C
-200 to +1200 °C
-200 to +600 °C
-270 to +400 °C
-200 to +1372 °C
-200 to +1000 °C
-100 to +1300 °C
0 to 1768 °C
0 to 1768 °C
0 to 1820 °C
0 to 2495 °C
0 to 2320 °C
0 to 2400 °C
-200 to +800 °C
-200 to +1372 °C
0 to 1395 °C ±0.1 %
±0.1 % from -100 °C
±0.1 % from -150 °C
±0.1 % from -150 °C
±0.1 % from -80 °C
±0.1 % from -80 °C
±0.1 % from -80 °C
±0.15 %
±0.15 %
±0.15 % from 400 °C
±0.15 % from 500 °C
±0.15 % from 500 °C
±0.15 % from 500 °C
±0.15 % from -80 °C
±0.1 % from -80 °C
±0.15 %
Shortest span Type L, J, U, T, K, E, N, chromel-alumel, PLII: 100 °C
Type S, R, B, D, C, W3Re/W26Re, chromel-copel: 500 °C
Range start/end freely programmable within the limits, in 0.1 °C steps
Cold junction Pt100 internal or thermostat external constant
Cold junction accuracy (internal) ±1 °C
Cold junction temperature (external) -50 to +150 °C adjustable
Sampling cycle Channel 1 to 18: 125 ms in total
Input filter 2nd order digital filter; filter constant adjustable from 0 to 10.0 sec
Electrical isolation see “Electrical data” on page 35 and
“Overview of the electrical isolation” on page 19
Resolution > 14 bit
Features also programmable in °F
Designation Connection
circuit Measuring range Accuracy
a
Measurement
current
Pt100 EN 60751
(TC = 3.85*10
-3
1/°C)
2-/3-wire
2-/3-wire
4-wire -200 to +100 °C
-200 to +850 °C
-200 to +850 °C ±0.5 °C
±0.8 °C
±0.5 °C
 
250 µA


250 µA


250 µA
Pt100 JIS 1604
(TC = 3.917*10
-3
1/°C)
2-/3-wire
2-/3-wire
4-wire -200 to +100 °C
-200 to +650 °C
-200 to +650 °C ±0.5 °C
±0.8 °C
±0.5 °C
 
250 µA
 
250 µA


250 µA
Pt100 GOST 6651-94 A.1
(TC = 3.91*10
-3
1/°C)
2-/3-wire, 4-wire
2-/3-wire, 4-wire -200 to +100 °C
-200 to +850 °C ±0.5 °C
±0.8 °C


250 µA
 
250 µA
Pt500 EN 60751
(TC = 3.85*10
-3
1/°C)
2-/3-wire, 4-wire
2-/3-wire, 4-wire -200 to +100 °C
-200 to +850 °C ±0.5 °C
±0.9 °C
 
100 µA
 
100 µA
Pt1000 EN 60751
(TC = 3.85*10
-3
1/°C)
2-/3-wire
2-/3-wire
4-wire -200 to +100 °C
-200 to +850 °C
-200 to +850 °C ±0.5 °C
±0.8 °C
±0.5 °C


100 µA
 
100 µA
 
100 µA
