General characteristic data
Approvals/approval marks
Circuit options - Three-phase economy circuit in master/slave operation
Operating modes - Impulsgruppenbetrieb für ohmsche Last oder Trafolast mit Softstart
Special features - Dual energy management
- Burst-firing mode with softstart
Subordinate control loop U² control as standard
Can be switched over to U, I, I², P control depending on device type
Electrical connection For type 709062/X -0X-020...
Control and load leads are connected via screw terminals.
For type 709062/X -0X-032...
Control leads are connected via screw terminals and load leads via cable lugs DIN 46235 and DIN46234 or
tubular cable lugs.
Operating conditions The controller is designed as a panel-mounting device according to: EN 50 178,
pollution degree 2, overvoltage category Ü III
Electromagnetic
compatibility According to DIN 61326-1
Emitted interference: Class B
Interference resistance: Industrial requirements
Protection rating All device types IP20 according to EN 60 529
Protection rating Protection rating I, with isolated control circuitry for connection to SELV circuits
Permissible
ambient temperature range 35°C with forced air cooling (250A controller)
0 … 45°C with natural air cooling (extended temperature range class 3K3 according to EN 60 721-3-3)
At higher temperatures, operation with reduced type current is possible.
(from 45°C with type current -2%/°C)
Permissible
storage temperature range -30 … +70°C (1K5 according to EN 60 721-3-1)
Cooling - Natural convection up to a load current of 200A
- For a load current of 250A, forced convection with built-in ventilator
Environmental performance Rel. humidity
≤
85 % annual average, no condensation 3K3 according to EN 60 721
Installation position Vertical
Test voltage According to EN 50178
Creepage distances 8 mm between supply current circuit and SELV circuits for type 709062/X -0X-020...
12.7 mm between supply current circuit and SELV circuits from type 709062/X -0X-032...
SELV = Separate Extra Low Voltage (safe low voltage)
Case Plastic, flammability class UL94 V0, color: Cobalt blue RAL 5013
Power dissipation The power dissipation can be calculated using the following empirical formula:
P
v
= 2 x (20W + 1.3V x I
Load
A)
Maximum temperature of the
cooling body 110°C
Type
(Load current) 20A 32A 50A 100A 150A 200A 250A
Weight approx. 2.2 kg approx. 4.2 kg approx. 5.4 kg approx. 7.6 kg approx. 17 kg approx. 19 kg approx. 20.4 kg
Approval
mark Testing agency Certificates / certification
numbers Inspection basis Valid for
c UL us Underwriters Laboratories submitted UL 508 All device Versions
