21
2 Mounting
4 Move the router module (A) to the left (A3) until the side contacts on the right side of the
router module are exposed.
5 Insert a suitable screwdriver (C) into the unlocking slot of the router module (A4) and press
upward (C5).
6 Pivot the router module (A) upward off the DIN rail (A6) and remove it.
Step Activity
