2014-04-15/00529103

Data Sheet 705000

Page 3/10

JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14

36039 Fulda, Germany

Postal address:

36035 Fulda, Germany

Phone:

+49 661 6003-0

Fax:

+49 661 6003-607

E-mail:

[email protected]

Internet:

www.jumo.net

JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:

+44 1279 635262

E-mail:

[email protected]

Internet: www.jumo.co.uk

JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866

1-800-554-5866

Fax:

315-437-5860

E-mail:

[email protected]

Internet: www.jumousa.com

Interfaces

The connection to PC programs (setup, evalu-
ation, visualization and PLC programming)
and higher-ranking systems is established via
standardized interfaces.
The following interfaces are available:
• LAN (Ethernet)

(HTTP or Modbus/TCP as master/slave)

• Serial RS232

(Modbus RTU as master/slave)

• Serial RS422/485

(Modbus RTU as master/slave)

• PROFIBUS-DP as slave (as of system ver-

sion 02)

• USB device/host
The connection of additional devices (barcode
scanner, paperless recorder, power controller,
etc.) is possible.

Voltage supply

The measuring, control, and automation sys-
tem operates at a voltage supply of DC 24 V.
The supply is only required at the base unit
(central processing unit), at the router module,
and at the multifunction panel.

System extension (system ver-

sion 02)

An extension of the setup program and the
system software enables the measuring, con-
trol, and automation system to provide new
features which are designed, for example, to
be used in process engineering:
• Program generator with process steps
• Extended user administration
• Extended process screen editor
