Operator responsibility – Safety recommendations
10
2.4. Technical specifications
Heating Immersion Circulator MA
Working temperature range °C 20 ... 200
Temperature stability °C ±0,01
Overall dimensions (WxDxH) cm 13x15x33
Usable bath depth cm from 8 to 14.5
Weight kg 4.0
All measurements have been carried out at: rated voltage and frequency
operating temperature: 70 °C ambient temperature: 20 °C bath fluid: water
Technical changes without prior notification reserved.
Mains power connection
208V - 230V; 50Hz - 60Hz
V; Hz
187 - 253; 50 - 60 (perm. range)
Current draw (at 208V) A 8
Current draw (at 230V) A 9
Mains power connection
100V - 115V; 50Hz - 60 Hz
V; Hz
90 - 127; 50 - 60 (perm. range)
Current draw (at 100V) A 8
Current draw (at 115V) A 9
MA
Temperature selection digital
via keypad indication on MULTI-DISPLAY(LED)
remote control via personal computer indication on monitor
Temperature indication MULTI-DISPLAY (LED)
Resolution (-9.99 …. +99.99 = 0.01) °C 0.01 / 0.1
Absolute Temperature Calibration °C ±3
Temperature control PID
Heater wattage (at 230 V) kW 2,0
Heater wattage (at 115V) kW 1,0
Electronically adj. pump capacity stages 1 ... 4
Flow rate max.at 0 bar l/min 11 ... 16
Pressure max. max. at 0 l bar 0.23 ... 0.45
Electrical connections:
External alarm device Vdc/mA 24-0 / max. 25
Computer interface RS232
Ambient temperature °C 5 ... 40
