F250, F500, F1000
1.951.4806-V1 7
4. Technical specifications
4.1. F250
Recirculating Cooler F250
Working temperature range °C -10 ... +40
Temperature stability °C ±0.5
Temperature selection: digital
via key pad indication on LED-DISPLAY
Temperature indication: LED-DISPLAY
Adjustment and display resolution °C 0.1
Temperature control PID 1
Temperature sensor Pt 100
Excess temperature protection 85 °C - fixed value
Low liquid level protection float switch
Circulating pump:
discharge, max.at 0 bar l/min 15
pressure, max. at 0 Liters bar 0.35
Filling level indicator sight glass
Filling volume from ... to Liters 1.7 ... 2.6
Dimensions (WxLxH) cm 24x40x52
Weight kg 27.0
Ambient temperature range °C 5 ... 40
Return flow temperature max. °C 80
Cooling compressor 1- stage / air cooled
Refrigerant R134a
Cooling capacity
at 100 V / 60 Hz at 115 V / 60 Hz

at 200 V / 60 Hz at 230 V / 60 Hz

at 230 V / 50 Hz

at 100 V / 50 Hz at 200 V / 50 Hz
Medium: Mixture water-glycol
°C
W
°C
W
+20 +15 +10 +5
0 -5 -10
250 240 220 210 180 90 60
+20 +15 +10 +5
0 -5 -10
220 210 195 185 170 80 40
Mains power connection V/ Hz 230
±10 % / 50
Current draw (at 230 V) A 3.0
Mains power connection V/ Hz 230
±10 % / 60
Current draw (at 230 V) A 2.0
Mains power connection V/ Hz 200 -5 %; +21 % / 50-60
Current draw (at 200 V / 50 Hz)
(at 200 V / 60 Hz)
A
A 2.0
2.1
Mains power connection V/ Hz 115
±10 % / 60
Current draw (at 115 V) A 4.0
Mains power connection V/ Hz 100
±10 % / 50-60
Current draw (at 100 V / 50 Hz)
(at 100 V / 60 Hz)
A
A 5.0
4.7
All measurements have been carried out at: rated voltage and frequency
ambient temperature: 20 °C. Technical changes without prior notification reserved.
