JULABO F1000 Recirculating Cooler - Manual (Page 8)

Technical specifications
8 1.951.4806-V1
4.2. F500
Recirculating Cooler F500
Working temperature range °C 0 ... +40
Temperature stability °C ±0.5
Temperature selection: digital
via key pad indication on LED-DISPLAY
Temperature indication: LED-DISPLAY
Adjustment and display resolution °C 0.1
Temperature control PID 1
Temperature sensor Pt 100
Excess temperature protection 85 °C - fixed value
Low liquid level protection float switch
Circulating pump:
discharge, max.at 0 bar l/min 24
pressure, max. at 0 Liters bar 0.5
Filling level indicator sight glass
Filling volume from ... to Liters 5,0 ... 7,5
Dimensions (WxLxH) cm 37,5x44x59
Weight kg 34.0
Ambient temperature range °C 5 ... 40
Return flow temperature max. °C 80
Cooling compressor 1- stage / air cooled
Refrigerant R134a
Cooling capacity
at 230 V / 50 Hz
Medium: Mixture water-glycol
°C
W
+20 +10 +5
0
500 400 300 250
Mains power connection V/ Hz 230 -10 %; +7 % / 50
Current draw (at 230 V) A 2.6
Mains power connection V/ Hz 230
±10 % / 60
Current draw (at 230 V) A 2.5
Mains power connection V/ Hz 115
±10 % / 60
Current draw (at 115 V) A 5.8
Mains power connection V/ Hz 100 -5 %; +10 % / 50-60
Current draw (at 100 V / 50 Hz)
(at 100 V / 60 Hz)
A
A 5.9
5.5
All measurements have been carried out at: rated voltage and frequency
ambient temperature: 20 °C
Technical changes without prior notification reserved.
