Warranty
All DMX 6-PORT MERGER models come with a standard one (1) year
limited warranty. Extended warranties of up to ten (10) years are available at
the time of purchase.
For details visit www.johnsonsystems.com/warranties.htm
For Technical Assistance
1. Refer to your product user manual. The most current revision is
available online: www.johnsonsystems.com/literature.htm
2. Contact the “point-of-sale” dealer or distributor from which this product
was originally purchased, and ask for technical assistance.
3. If neither of the above can provide you with the necessary information,
please contact our factory via email ([email protected])
or phone (403-287-8003) during business hours (Monday to Friday,
8:00AM to 5:00PM MST).
Contents
Introduction ......................................................................................................3
Characteristics .................................................................................................4
Drawings & Details ..........................................................................................4
Example Application Riser Diagrams ..............................................................6
Installation .......................................................................................................8
Mounting Options ............................................................................................8
Power Supply Input Connections ....................................................................9
DMX Input/Output Connections ....................................................................10
DMX-6PM Controller Board ...........................................................................13
User Interface ................................................................................................14
System Status • LED Indicators ....................................................................15
System Status • LCD Display ........................................................................15
Quick Programming Reference to System Configuration Menu Items ..........16
Detailed Programming of System Configuration Menu Items........................16
USB Tech Port Operation ..............................................................................19
