Johnson Systems DMX 6-PORT MERGER User Manual
User manual, Dmx 6-port merger, Johnson systems inc

R
E
CY
CLE
RE
U
S
E
R
ET
ROFIT
!
User Manual
DMX 6-PORT MERGER
Model
Description
DMX-6PIM
6-PORT Installation Merger for permanent hardwired installations
DMX-6PIM-FM
Flush Mount version of DMX-6PIM above
DMX-6PM-XLR
Portable 6-PORT Merger with 5 pin XLR connectors
DMX-6PM-XLR-RM
19" Rack Mount (1RU) 6-PORT Merger with 5 pin XLR connectors
DMX-6PM-TB
Portable 6-PORT Merger with “break-away” terminal block DMX connectors
DMX-6PM-TB-RM
19" Rack Mount (1RU) 6-PORT Merger with “break-away” terminal block DMX connectors
DMX-6PM-RJ45
Portable 6-PORT Merger with RJ45 “Ethercon” connectors
DMX-6PM-RJ45-RM
19" Rack Mount (1RU) Merger with RJ45 “Ethercon” connectors
* PC not included. Requires Windows. PowerTerm software not included.
JOHNSON SYSTEMS INC.
Table of contents
Document Outline
- Introduction
- Characteristics
- Drawings & Details
- Example Application Riser Diagrams
- Installation
- Mounting Options
- Power Supply Input Connections
- DMX Input/Output Connections
- DMX-6PM Controller Board
- User Interface
- System Status • LED Indicators
- System Status • LCD Display
- Quick Programming Reference to System Configuration Menu Items
- Detailed Programming of System Configuration Menu Items
- USB Tech Port Operation
