DIGI-88B Installation Guide
RS232, RS485, and TCP/IP System Commands
Misc. Commands
Function Command Response
Get Device Type br aDIGI-88B ASCII string containing the
letter “a” followed by the
name of the device
Get Device Status bc
>
Ex:
s11
s22
s33
s44
s55
s66
s77
s88
ASCII string in the format of:
“s1Ys2Ys3Ys4Ys5ys6Ys7Ys8Y”
where Y is the input source
being routed to each output.
Each segment is separated by
a .
The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4 etc…
The output channels map as
follows:
s1 = output 1
s2 = output 2
s3 = output 3
s4 = output 4 etc…
Get IP Mode and
Address
gipm Static IP Ex:
GIPM
ipmsip192168001114
>
ASCII string containing
“GIPM followed by
IP mode, the IP address,
The value of the IP mode map
as follows:
sip = Static IP Mode
dhc = Dynamic IP Mode
DHCP IP Ex:
GIPM
ipmdhc192168001101
R>
Misc. Commands
Function Command Response
Set IP Mode - DHCP dhc “DHCP”
Set IP Mode - Static sip www xxx yyy zzz
Where:
www = 1 st octet
xxx = 2 nd octet
yyy = 3 rd octet
zzz = 4th octet
Each octet is separated by a
.
Ex: Set IP to 192.168.1.114:
sip192168001<
SP>114
Ex:
IP192168001114
>
ASCII string that includes the IP
address set by the command.
“IP www xxx yyy zzz”
***When using this command
via a TCP/IP connection, the
response may be truncated
due to the loss of
communications caused by
changing the IP address.
