DIGI-88B Installation Guide
Static IP assignment via TCP/IP
The Static IP address can be changed using TCP/IP
1. Download Docklight and the DIGI-88B from the Intelix website.
2. Connect a network crossover cable (not included) between your computer and the DIGI-88B LAN
Port.
3. Change the IP address of your computer to fit in the same subnet as the DIGI-88B current IP
address. The unit’s default IP address is 192.168.0.178, so set your IP address to 192.168.0.177
for first time connection. To change your computer’s IP address in Windows7, follow this path
(START Menu -> Control Panel -> Network and
Internet -> Network and Sharing Center)
a. Select “Local Area Connection”
b. Select “Properties”
4. Select “Internet Protocol Version 4 (TCP/IPv4)”,
then select “Properties”.
